Outdoor Rental 500x1000mm

Outdoor Rental LED Display

Outdoor rental LED panel is a popular solution available in several pixel pitches. It is a lightweight modular design which can be easily set up into different screen sizes. All these panels are with high brightness for outdoor environment.

Product Description

Slim, lightweight and strong structure

Panel size in 500x500mm and 500x1000mm, mixed built-up is available for different demands. Die-cast aluminum cabinet makes it sure for the reliable structure and precise seamless. It is in 8kg/panel and 80mm in depth.

Fast locking system, curve available

Cabinets are with fast locking system, no tools needed for installation. And concave and convex designs are available. Curved locks can be added to make concave and convex designs. It can also be built with PixelFlex series panels.

Different pitches are with the same mechanical frame

All pixel pitches are with the same cabinet, and only with different pixels. P2.6, P2.9, P3.91 and P4.8 for outdoor use.

Easy maintenance

Front service, modules, power box can be dismantled from front and back.

High brightness and waterproof

Brightness are more than 4500nits, and it is with IP65 front and IP54 rear for outdoor rental environment.

Parameter

Item	Parameter
Model No.	P2.6	P2.97	P3.91
Pixel configuration	1R1G1B
LED type	SMD1415	SMD1415	SMD1921
Density（dots/m²）	147,456	112,896	65,536
Module size（mm）	250x250
Module resolution	96x96	84x84	64x64
Cabinet size（mm）	500x1000	500x1000	500x1000
Cabinet resolution	192x192	168x168	128x128
Scan method	1/24	1/21	1/16
Brightness（nits）	≥4,000	≥4,500	≥4,500
Refresh rate（Hz）	≥3,840	≥3,840	≥3,840
Weight（kg/m²）	13 kg/panel
Cabinet material	Die-cast aluminum
Protection level	IP65 front, IP54 rear
Maintenance	Rear and front
